Honeywell MU-TLPA02 51304467-100 Power Adapter Board

If you don't find the model you want in our webpage, please contact us without hesitation! For more product details, please contact us！！

Product Description:

Power Adapter Board (MU-TLPA02)

Brand：Honeywell

Additional Information

● LLMux, SI, SDI Power Adapter FTA - MU-TLPA02

● Not CE compliant, not conformally coated

● Circuits - 2

● Terminals - Compression

● Size A - 6 inches (152 mm)

● MODBUS Serial Interface Model Numbers

● SI FTA Model Number: MU-TSIM12

● SI IOP Model Number: MU-PSIM11

● Power Adapter FTA Model Number: MU-TLPA02

MODBUS Serial Interface Specifications

● Interface Type: EIA-232-D or EIA-485

● Number of Serial Channels: 2 per IOP, 1 per FTA

● Distance-Power Adapter to FTA: 300 m

● Protocol: Modbus

● Transmission Mode: RTU

● Serial Line Mode: RS232 or RS485

● Selectable Baud Rates: 1200, 2400, 4800, 9600,19,200 bps

● Serial Data Format: 8 data bits with programmable 9th bit (parity)

● Selectable Parity: None, odd, or even

● Common Mode Operation: 250 V RMS (continuous)

● Surge Protection: IEEE SWC 472-1974

● ESD Protection: IEEE 801.2

● Number of Stop Bits: 1

● Modem Control Support: Selectable On/Off

● Keep Alive Cell Write: Configurable address

● Message Response Timeout Time: Configurable timeout

● Exception Errors Reported: Keep-Alive, Message Response

● Timeout, Signaling Mode/Modem Support, Baud Rate, Parity

● Data Formats Supported: Boolean, Real, ASCII Strings, Signed Integers, Unsigned Integers

● Inter-Message Stall Time: 3.5 Character Time minimum

● EIA-232-D SUPPORT

● Interface Type: Serial asynchronous

● Lines Supported: TXD, RXD, RTS, CTS, DSR, DTR, Logic GND, Protective GND (Compatible with CCIT V.24; CCIT V.28)

● Distance – FTA to Device: 15 meters (cable cap. = 2500 pF max.)

● EIA-485 SUPPORT

● Interface Type: Serial asynchronous Half Duplex only

● Lines Supported: Two-wire, differential pair: DATA+, DATA-, Protective GND (shield)

● Number of Transceivers: 15 drops maximum

● Distance – FTA to Device: 1.2 Km (4000 ft) max
